ExaGrid Product portfolio
The ExaGrid Tiered Backup Storage product line comprises seven appliance models, each tailored for both full backup and long-term retention purposes.
Customers have the flexibility to mix and match any ExaGrid appliance within the same scale-out system, regardless of size or age, enabling a pay-as-you-grow approach with the capacity to accommodate up to 32 appliances.
A unified user interface manages all appliances and systems, facilitating the deployment of multiple systems at a single site and enabling full backups up to petabytes in size.
ExaGrid provides a range of appliance models that can be combined in a single scale-out system of up to 32 appliances. The largest scale-out system can handle up to a 6PB full backup, offering the market's most extensive single scale-out system storage capacity for backup storage solutions.
ExaGrid Appliances
| ExaGrid Model | Raw capacity (TB) | Usable capacity (TB) | Capacity for Weekly Full (TB) | Max Backup Thruput (TB/hr) | Form Factor | Optional encryption At Resr SEC |
| EX27 | 72 | 54 | 27 | 6,09 | 2U | YES |
| EX36 | 96 | 72 | 36 | 7,78 | 2U | YES |
| EX54 | 162 | 108 | 54 | 5,81 | 2U | YES |
| EX84 | 192 | 168 | 84 | 15,25 | 2U | YES |
| EX189 | 432 | 378 | 189 | 16,14 | 2U | YES |
Moreover, ExaGrid provides these appliances tailored for extensive organizations with smaller data center sites globally:
ExaGrid Appliances for a larger accounts with smaller data center locations
| ExaGrid Model | Raw capacity (TB) | Usable capacity (TB) | Capacity for Weekly Full (TB) | Max Backup Thruput (TB/hr) | Form Factor | Optional encryption At Resr SEC |
| EX10 | 32 | 20 | 10 | 2,40 | 2U | YES |
| EX18 | 48 | 36 | 18 | 3,60 | 2U | YES |
Please note that these values pertain to the currently available ExaGrid models in circulation and may not correspond to older models featuring diverse disk sizes and configurations.
EX189
Expands to 32 appliances within a single scale-out system, enabling a full backup of 6PB or 516TB/hr. Below examples of system configurations:
| ExaGrid Model | Usable capacity (TB) | Capacity for Weekly Full (TB) | Max Backup Thruput (TB/hr) | Form Factor |
| EX378-G | 756 TG | 378 TB | 32.38 | 4U |
| EX1134-G | 2.26PB | 1.13. PB | 96.84 | 12U |
| EX2268-G | 4.53PB | 2.26 PB | 193.68 | 24U |
| EX3024-G | 6.04 PB | 3.02 PB | 258.24 | 32U |
| EX3780-G | 7.56 PB | 3.78 PB | 322.80 | 40U |
| EX4725-G | 9.45 PB | 4.72 PB | 403.50 | 50U |
| EX6048-G | 12.09 PB | 6.04 PB | 516.48 | 64U |
Source: ExaGrid official Announcement
